Name: Parker AC70 Stack Only IP20 AC3PH, 400V – 355kW 740-4K0440-BN-0S-0000
SKU: 740-4K0440-BN-0S-0000
Price: 9844.75 GBP
Availability: BackOrder

The Range:
The AC30 & AC70 (Stack Only) comes in 2 power variations: AC Fed (3PH, 380V / 480V) & DC Fed (3PH, DC 510V / 650V).
The AC30 comes in 3 further variations: Versatile (V), Advanced Inverter (P), Advanced Inverter (Dual Encoder) (D).

Frame Sizes:
Below are the power ratings for the different options and frame sizes. TOF = Top of Frame.

AC70

3PH, 380V / 480V (400V)
Frame D (1.1, 1.5, 2.2, 3, 4, 5.5) kW [TOF: 710-4D0012-BE-0S-0000]
Frame E (7.5, 11) kW [TOF: 710-4E0023-BE-0S-0000]
Frame F (15, 18) kW [TOF: 710-4F0038-BE-0S-0000]
Frame G (22, 30, 37) kW [TOF: 710-4G0073-BE-0S-0000]
Frame H (45, 55, 75) kW [TOF: 710-4H0145-BE-0S-0000]
Frame J (90, 110, 132) kW [TOF: 710-4J0260-BE-0S-0000]
Frame K (160, 200, 250) kW [TOF: 710-4K0440-BE-0S-0000]

3PH, DC 510V / 650V (500V DC)
Frame D (1.1, 1.5, 2.2, 3, 4, 5.5) kW [TOF: 740-4D0012-BN-0S-0000]
Frame E (7.5, 11) kW [TOF: 740-4E0023-BN-0S-0000]
Frame F (15, 18) kW [TOF: 740-4F0038-BN-0S-0000]
Frame G (22, 30, 37) kW [TOF: 740-4G0073-BN-0S-0000]
Frame H (45, 55, 75) kW [TOF: 740-4H0145-BN-0S-0000]
Frame J (90, 110, 132) kW [TOF: 740-4J0260-BN-0S-0000]
Frame K (160, 200, 250) kW [TOF: 740-4K0440-BN-0S-0000]

Frame Dimensions:
Frame D (100(W) x 286(H) x 255(D) mm) – approx. 4.5kg
Frame E (125(W) x 333(H) x 255(D) mm) – approx. 6.8kg
Frame F (150(W) x 383(H) x 255(D) mm) – approx. 10kg
Frame G (220(W) x 480(H) x 287(D) mm) – approx. 22.3kg
Frame H (260(W) x 670(H) x 316(D) mm) – approx. 42.8kg
Frame J (330(W) x 800(H) x 374(D) mm) – approx. 89kg
Frame k (400(W) x 1310(H) x 457(D) mm) – approx. 125kg

Options:
There are a number of external options available for the drive for the drive:
Blank Plate [7001-01-00]
Keypad [7001-00-00]
Control Module (Versatile) [30V-0S-0000]
Control Module (Advanced Inverter) [30P-0S-0000]
Control Module (Advanced Inverter) [30D-0S-0000]

Part Code

740-4K0440-BN-0S-0000

Commodity Code

85044084

Manufacturer

Parker Hannifin

£9,844.75

Buy New

Available on backorder

for Lead Time

Ask about our lead times for backorders

Get in touch and we'll get back to you about the time it will take to get this product to you.

Company Name*
Job Title*
First Name*
First
Last Name*
Email*
Business Phone
Country*
Post/Zipcode
Message*
Comments
This field is for validation purposes and should be left unchanged.

£9,844.75ex VAT

List price - £13,976.69 ex VAT

£11,813.70inc VAT

Supplied with 12 month manufacturer’s warranty

SKU: 740-4K0440-BN-0S-0000 Categories: 3 Phase AC Drives, Parker AC70 Range, Variable Frequency AC Drives Tags: AC Drives, AC70, Parker, Parker AC70, Parker Hannifin

Need this repaired?

Give us a call and send it our way. Our engineers can restore it or offer a replacement so your systems run better than before - and with 12 months warranty too.
